Bose 201 owners guide

Page 1

2 Contents Declaration of Conformity We, the offerer: Bose ® Corporation, The Mountain Framingham, MA 01701-9168 USA acknowledge our sole responsibility, that the product: Kind of equipment: Loudspeakers Type designation: 201 ® and 301 ® Series V Direct Reflecting ® speakers in accordance with EMC Directive 89/336/EEC and Article 10(1) of the Direc- tive, is in compliance with the following norm(s) or document(s): Technical regulations: EN50081-1, EN50082-1 Accredited by Bose Corporation 22 March 2002 Bose B.V., Nijverheidstraat 8 Nick Merks 1135 GE Edam, The Netherlands Vice President Europe Manufacturers authorized EU Representative Where to find... Setting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Unpack the carton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 For your records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Select the locations for your 201 ® or 301 ® speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Choose the cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Prepare the cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Make the connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Test the speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Using and Maintaining Your Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Enjoying sound in a variety of ways . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Cleaning the speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Warranty period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 ©2002 Bose Corporation. No part of this work may be reproduced, modified, distributed or otherwise used without prior written permission.

Page 2

3 Setting Up Before you begin Your 201 ® or 301 ® Series V Direct/Reflecting ® speakers recreate a natural balance of reflected and direct sound energy for an open, spacious performance. They are designed by Bose ® to bring you high-quality listening pleasure. These speakers are significantly different from conventional speakers, so be sure to read this owners guide. It will help you set up and use your speakers properly, for the greatest enjoy - ment. Unpack the carton Carefully unpack the carton and save all packing materials for possible future use. Check the carton contents ( Figure 1 ). If either speaker appears damaged, do not use them. Instead, repack both speakers in the original carton and notify your authorized Bose dealer immediately. Note: Now is a good time to record the speaker serial numbers below and on your warranty card. CAUTION: To avoid danger of suffocation, keep the plastic bags that wrap these speakers out of the reach of children. Figure 1 What comes in the carton 201 ® series V speakers 301 ® series V speakers For your records Serial numbers are located on the back of each speaker. Serial number: ____________________ and______________________________ Dealer name: _________________________________________________________ Dealer phone: ____________________ Purchase date ____________________ We suggest you keep your sales slip and warranty card together with this owners guide.
