Page 1
20
Table of contents
Features ........................................................................\
............................................... .................. 21
T raffic safety and precautions ........................................................................\
................................ 22
Important note ........................................................................\
......................................... ............... 22
Detachable face (release panel) ........................................................................\
........................ .... 23
Location of controls ........................................................................\
................................... ............. 24
Instructions -“ general operation ........................................................................\
....................... ..... 26
Audio operation ........................................................................\
........................................ .............. 27
Radio operation ........................................................................\
........................................ ............. 28
T ape player operation ........................................................................\
............................................ 29
Changer control (when optional CD changer is connected) ........................................................... 30
DSC menu (Direct Software Control) ........................................................................\
..................... 33
Infrared eye for wireless remote control ........................................................................\
............... .. 36
Auxiliary input jack (cable connection with ø 3.5 mm pigtail coupler\
) ............................................ 36
Specifications ........................................................................\
......................................................... 37
Blaupunkt Telephone Hotline
Address of the next service centre in your vicinity
(only for Germany)
If you would like to know the address of the next Blaupunkt service cent\
re of your area
without having our service list at hand:
- Find out your area code.
- Then call the following chargeable phone number: 01 80 / 5 25 56 66.
- Using the area code to be entered you will be automatically given the ad\
dress and
phone number of the next Blaupunkt service centre. You can also request \
this infor-
mation by fax.
Page 2
21
ENGLISH
Features
Its high-power amplifier and 4-channel preamp output provide you with tr\
emendous system
configuration flexibility. Its auxiliary input jack lets you easily \
incorporate portable audio
equipment, such as a portable tape or DAT player, into your cars sou\
nd system.
-Radio features
-Codem III concept, i.e.
new tuner, assessment of multipath interference, automatic noise suppres\
sion (ASU),
gradual mono/stereo switching, volume control as a function of signal st\
rength.
- Superior AM frequency response
- 18 FM/6 AM presets, including 6 FM and 6 AM Travelstore presets
- Station and preset scan
- Station naming
- Tuner timer
- Local/distant seek and manual tuning
- Tape player features
-Full-logic autoreverse cassette mechanism
- S-CPS (Super Cassette Program Search)
- Fast forward and rewind
- Radio monitor
- Tape scan
- Adjustable blank skip
- CD changer control features (optional)
-CDC-A 05 changer control
- Disc naming, disc list
- Disc/track up/down
- Disc/track scan, repeat, track mix
- Track Program Memory (TPM)
- Cue/review, pause/play
- Audio features:
-35 watts x 4 channel integrated amplifier
- 4-channel preamp output
- Bass, treble, balance and fader control
- Source tone memory
- Programmable Loudness
- Mute, also when using cellular phone
- Auxiliary input
- Other features:
-DSC menu (Direct Software Control)
- Integrated infrared eye for RC 06 H wireless remote control (optional)\
- Detachable face with hard-shell case
- Illumination
- Clock recall
- 179 x 50 x 150 mm DIN/ISO chassis
- Detachable wire harness
- Snap-in DIN sleeve and mounting hardware
Your units detachable faceplate makes the unit useless to would-be t\
hieves.
Designed, engineered and manufactured by Blaupunkt.
