Page 1
ENGLISH
E-1
Precautions
This equipment has been tested and found to comply with the
limits for a Class B device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable pro-
tection against harmful interference in a residential installa-
tion. This equipment generates, uses, and can radiate radio
frequency energy, and, if not installed and used in accord-
ance with instructions, may cause harmful interference with
radio communications. However, there is no guarantee that
radio interference will not occur in particular installation. If this
equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to consult the dealer
or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not ex-
pressly approved in this manual could void your authority to
operate this equipment. Features - MP3/WMA file playback support
- CD-TEXT support (SONG, ALBUM)
- Detachable flip down front panel
- Built-in power amplifier
(max. output : 50W × 4ch)
- FM/AM PLL Synthesizer tuner
- 30 Station preset memory
- Travel Store / Scan tuning
- X-BASS System
- Station / Disc name store, Station / Disc call
- Auxiliary input
- IR Remote Control RC-823
- CD changer control
(IDCA09, CDCA08 & CDCA071*)
* CDCA071 requires adaptor # 7607 898 093 available
separately.
FCC WARNING
- Avoid installing the unit where it would be subject to high
temperatures, such as in direct sunlight or a hot air stream
from the heater, or where it would be subject to dust, dirt, or
excessive vibration.
-Do not turn on the unit if the temperature inside the car is
very high. Always cool down the unit before usage. Parking
your car in direct sunlight will result in a temperature rise.
-If the unit does not turn on, check the connections first. Then
check whether the fuse at the back of the unit is blown.
-Carefully read this manual before using the unit. If you en-
counter any problems that are not covered in this manual,
please consult the dealer where you purchased the unit or
the dealer nearest to you.
-This unit has been designed specifically for playback of com-
pact discs bearing the following mark. Other discs cannot
be played.
Handling Compact Discs -Be careful when removing a compact disc after the play-
back is completed because the disc may be extremely hot.
-Do not use non-conventional discs such as heart-shaped,
octagonal discs, etc. The player could be damaged.
-Do not expose compact discs to direct sunlight or any heat
source.
-Check all compact discs before playing, and discard cracked,
scratched or warped discs.
-Wipe dirty or damp discs outward from the centre with a
soft cloth.
-Do not use any solvents such as commercially available
cleaners, antistatic spray, or thinner to clean the compact
discs.
-If a label is affixed to a disc, the label may prevent removal
of the disc from the unit or may damage the unit.
Label
CD
Page 2
ENGLISH E-2
Notes - Be sure to use this unit with the front panel closed.
The unit is automatically switched off when the front panel
is left open for about 10 minutes.
- Do not handle the unit roughly when opening/closing the
front panel.
- Do not put any object or use it like a tray when the front
panel is open in a lying position.
- Do not press OPEN button when closing the front panel.
- Do not put too much force to the operation buttons or the
display window as it may cause damage or deform the unit.
- Connectors on the unit and front panel are vital parts trans-
mitting the signal. Do not touch, push or scratch them.
- Be careful not to pinch your fingers or hands when opening
and closing the front panel.
- Do not press hard on the front panel when affixing it to the
unit. No more than light to moderate pressure should be
needed.
- Make sure there is no dust or dirt on the electrical terminals
on the back of the front panel as this could cause intermit-
tent operation or other malfunctions.
Detaching the Front Panel
EJECT button
3.
Close the inner cover.
Do not leave inner cover in the down position unless the
front panel is in place.
2.
Pull the front panel toward your direction to remove it.
1.
Press the
OPEN
firmly to open the flip down front panel.
Ejecting the CD Press the recessed button located to the left behind the Front
Panel.
Handling the Front Panel Attaching the Front Panel Place the right hand side of the front panel so that the parts
A of the front panel are engaged with the parts B of the unit
as shown below. Then push the left hand side of the front
panel until it is securely locked. Front Panel Open / Close Panel open Press the
OPEN
.
Panel close Raise the front panel with your
finger until it locks in place.
Security/Retailer Display Bolt the front panel with the locking screw (See page 19) in
the inner cover as shown below, to protect the front panel
from theft and from getting lost.
Locking screw
