Page 1
18
Ta ble of Contents
Features ........................................................................\
............................................... .................. 19
Tr affic Safety and Precautions ........................................................................\
......................... ...... 19
Detachable Face (Release Panel) ........................................................................\
........................ .20
Electrical Connections ........................................................................\
................................. .......... 21
Installation ........................................................................\
........................................... ................... 23
Maintenance ........................................................................\
.......................................................... 25
Location of Controls ........................................................................\
................................... ............ 26
Instructions -“ General Operation ........................................................................\
....................... .... 27
Audio Operation ........................................................................\
........................................ ............. 28
Radio Operation ........................................................................\
........................................ ............. 29
Cassette Tape Player Operation ........................................................................\
......................... ... 30
T roubleshooting Guide ........................................................................\
.................................. ........ 31
Blaupunkt Telephone Hotline ........................................................................\
............................ ..... 31
Specifications ........................................................................\
......................................................... 32
Page 2
19
ENGLISH
Features
-Radio Features
-15 FM/5 AM Presets, Including 5 FM and 5 AM Travelstore Presets
- Station Scan
- Local/Distant Seek and Manual Tuning
- Cassette Tape Player Features
-Auto-Reverse Cassette Mechanism
- True Fast-Forward/Rewind
- Hard Permalloy Tape Head
- Radio Monitor with Radio Preset Access
- Audio Features:
-10 Watts x 4 Channel Integrated Amplifier
- Adjustable Maximum Turn-On Volume
- Bass, Treble, Balance and Fader Control
- Loudness Button
- Mute Button
- Other Features:
-Detachable Face
- Illumination, Amber Night Design
- Display Priority Control
- Temporary Display Change Control
- Clock Recall
- 179 x 50 x 150 mm DIN/ISO Chassis
- Detachable Wire Harness
- Snap-In DIN Sleeve and Mounting Hardware
Your units detachable front faceplate makes the unit useless to woul\
d-be thieves.
Designed, Engineered and Manufactured By Blaupunkt.
T raffic Safety and Precautions
- Do not adjust your unit in difficult driving conditions that demand your\
full attention.
- As the driver of a motor vehicle, it is your responsibility to pay atten\
tion to the traffic situation
at all times. Never use your unit in a way that could distract you.
- Always make sure that you are still able to hear any warning signals com\
ing from outside of
the vehicle, such as police or fire engine sirens, so that you can react\
accordingly.
- If your vehicle was parked in direct sunlight resulting in a considerabl\
e rise in temperature
inside the vehicle, allow the unit to cool off before operating it.
