Page 2
13
ENGLISH
Table of contents Short instructions ........................ 14
Important notes ............................ 16 Precautions ........................................... 16
Traffic safety ......................................... 16
QuickOut ............................................... 16
Installation/Connection .......................... 16 Anti-theft protection ..................... 16 Entry of a wrong code number .............. 16
Switching on security coding ................. 17
Re-start following an interruption of the
power supply ......................................... 17
Switching off security coding ................. 17
CODE LED ............................................ 17
Radio operation with RDS ........... 18 AF - Alternative frequency .................... 18
REG - regional programme ................... 18
Selecting a waveband ........................... 18
Selecting a station ................................. 18Automatic tuning ................................ 18
Manual tuning .................................... 19
Selecting the seek tuning sensitivity ..... 19
Switching from stereo to mono (FM) ..... 19
Changing the memory bank .................. 19
Storing stations ..................................... 19
Automatically storing the strongest
stations with Travelstore ....................... 19 Recalling stored stations ....................... 20 Receiving traffic programme
stations with RDS-EON ................ 20 Traffic announcement priority on/off ..... 20
Warning beep ........................................ 20 Switching the warning beep off .......... 20
Automatic seek tuning start ................... 21
Adjusting the volume for traffic
announcements and the warning beep ...................................................... 21 Tape operation .............................. 21 Inserting a tape ..................................... 21
Removing a tape ................................... 21
Fast Forward ......................................... 21
Appendix ....................................... 21 Mechanism/cassette tapes ................... 21
Specifications ........................................ 22
Page 5
16 Important notes
the car radio from its bracket which enables
you to carry it out anywhere. The memory of
the preset buttons is maintained also for long
periods of time.
If you wish to remove the unit:
-Press button a and pull handle b
firmly.
If you wish to resume radio or cassette op-
eration:
- Push the unit into the bracket as far as
it will go and lock the handle into place
on the front plate.
Operation of the car radio can begin as long
as the security coding system is switched off.
If the coding system is active, proceed as
described in the chapter Re-start following
an interruption of the power supply each
time the unit is reinserted. Installation/Connection If you would like to install this equipment
yourself or add any new components, please
carefully read the installation and connection
instructions following the appendix.
Do not ground the loudspeaker outputs!
Use only the accessory and replacement
parts approved by Blaupunkt.
Anti-theft protection
Precautions Before starting to use your new car radio,
please read the information on Traffic safe-
ty and Anti-theft protection carefully. Traffic safety As the driver of a motor vehicle, it is your
responsibility to pay attention to the traffic
situation at all times. Never use your car radio
in a way that could distract you.
Please keep in mind that you travel a di-
stance of 14 m per second at a speed of only
50 km/h.
Should the traffic situation become particu-
larly demanding, we advise you not to use the
radio.
Always make sure that you are still able to
hear any warning signals coming from out-
side of the vehicle, such as police or fire
engine sirens, so that you can react accord-
ingly.
Therefore, you should always select a
moderate volume for playing your car radio
while you are driving. QuickOut This unit is available with or without the
QuickOut (quick release) option.
The QuickOut handle facilitates removal of This car radio is supplied with inactive code
protection. In order to switch the security
coding system on, proceed as described in
the following.
If the coding system is active while the power
supply to the system is interrupted (e.g. theft,
disconnection of the car battery), the set will
be electronically blocked. In such a case it
can only be made operable again by entering
the correct code number given in the car
radio passport.
Entry of a wrong code number It should not be possible for a thief to find out
the correct code number by trial and error.
This is why the set will be blocked for a certain
period of time after a wrong code number has
been entered. The display will then show
CODE ERR.
After the first three unsuccessful attempts
the system will lock for 10 seconds; after
further attempts, the waiting time extends to
one hour.
After 19 unsuccessful attempts the display
will show OFF. In this case you can no
longer re-start the unit.
Note:
Keep your car radio passport with the code
number in a safe place in order to avoid
