Page 1
3
2
Radio
3
CD
1
j i
9
b
9
d
a
c
g e
f h
6
1
10
2
3
4
5
8
9
7
QuickOut
a
b
QuickOut
Page 2
12 Front Panel Description 1ON/OFF
Switch on the set by turning knob 1.
2 AUD button (sound control/broader
interior sound impression)
BAS -“ Adjustment of the low frequen-
cies via buttons < > 7.
TRE -“ Adjustment of the high frequen-
cies via buttons < > 7.
BAL -“ Adjustment of the left/right volu-
me via buttons < > 7.
FAD -“ Adjustment of the front/rear vo-
lume via buttons < > 7.
3 FM-T button ( Frequency Modulation)
FM button
This button is used for shifting between
the different individual FM storage le-
vels and T (Travelstore).
4 M-L button ( Medium wave - Long
wave)
Use this button to select either the me-
dium wave (MW) or long wave (LW)
frequencies.
Press button again to shift between
MW and LW. 5
MIX-lo-m button
CD:
Use this button to play the CD titles in
an arbitrary order.
Radio:
Button to shift between the normal and
high-sensitivity manual station seek
mode, and mono switch.
6
- SRC button (Sou rce)
To shift between the individual audio
sources, e.g. CD -™¦ Radio -™¦ CD.
By pressing the
- SRC button 6 for
more than than 3 seconds, the CD is
ejected.
7 < > rocker switch
Radio:
Automatic station selection
CD:
Skipping to next/previous title.
Pressing the rocker switch < > longer
than 1 sec. activates fast forward (cue)
or fast reverse (review).
\b CD slot
Insert the CD with the label side sho-
wing to the top. 9
Display
: Preset buttons
Storing a station:
Keep button depressed during radio
operation until the station becomes
audible again.
Recalling a station:
Press button briefly.
