Audiolab 8200 cd owners manual

Page 1

This label tells you that the unit contains a Laser component. Opening the unit will expose the user to radiation from the laser beam. Mains supply and safety Mains Supply: The mains operating voltage of all Audiolab units is shown on the rear panel. If this does not match the voltage in your area, consult your dealer. The mains supply fuse is located on the rear panel of the unit. If it has broken, check for any obvious cause before replacing the fuse with one of the correct rating and type. The fuse values are: 220 - 240V (UK, Korea, etc.)T 1AL 20mm Slow Blow 100 - 120V (USA, Japan, etc)T 1.6AL 20mm Slow Blow The fuse is located in a slide-in carrier which also contains a spare fuse. The fuse carrier can only be pulled out after the IEC power cord is unplugged. When the carrier is opened the first fuse to be seen is the spare fuse. Remove and safely dispose of the fuse with the blown link before replacing it. Power Cord: An AC power cord is normally supplied with a mains plug suitable for your area. If you have any doubts, consult your dealer about obtaining a suitable power cord. Class II construction double insulated. This product must not be connected to earth. Important notice to UK users The appliance cord is terminated with a UK approved mains plug fitted with a A fuse. If 3the fuse needs to be replaced, an ASTA or BSI approved BS1362 fuse rated at 5A must be used. If you need to change the mains plug, remove the fuse and dispose of this plug safely immediately after cutting it from the cord. Connecting a Mains Plug The wires in the mains lead are coloured in accordance with the code: Blue: NEUTRAL; Brown: LIVE: As these colours may not correspond to the coloured markings identifying the terminals in your plug, proceed as follows: The BLUE wire must be connected to the terminal marked with the letter N or coloured BLUE or BLACK. The BROWN wire must be connected to the terminal marked with the letter L or coloured BROWN or RED. Use only attachments/accessories specified by the manufacturer. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Unplug this apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have CAUTION!RISK OF ELECTRIC SHOCK DO NOT OPENADVERTISSEMENT: RISQUE DE CHOC ELECTRIQUE- NE PAS OUVRIRTO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER NO USER-REMOVEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED PERSONNELThis symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit. 1: Statutory & Safety InformationAnalogue SpecificationsDigital SpecificationsGeneral Specifications Connectors: DAC:Operating Temperature Range: 2 pairs RCA phono24bit 192kHz, 5th order Sigma Delta10ºC-40 °C (ambient) Output Level:Output Format: Power Requirements: (Depending on Region) 2.4V rmsSPDIF50-60Hz 100 V, 110-120 V, and 220-240 V models available Frequency Response: Connectors: Power Consumption: 20Hz-20Khz +/- 0.5dB75ohm BNC, RCA phono, OpticalLess than 25W Output Impedance:Output Level:Dimensions (W x H x D): 100 Ohms 550mV p-p ( nom.) ±10%445 x 74 x 335 mm - including feet, terminals and controls S/N Ratio:Output Impedance: Weight Better than 100dBA75 Ohms ±5%Net: 6 kg Shipping: 7.4kg Channel Balance: Colour: Better than ± 0.5dB @ 1 kHz Silver Channel Separation: Accessories Supplied: Better than 100dB @ 1 kHz AC Power Cord THD+N (at 1kHz): Analogue Stereo RCA 2 Phono-2Phono interconnect Less than 0.003% 20Hz-20Khz Instruction Manual (>-90dB/2.4V) 8000RC Remote Control with 2 x AA batteries Audiolab reserves the right to alter design and specification without notice. Specification may vary for different countries. Audiolab is a member of the International Audio Group. 3A FUSE BS 1362 BROWN (Live) BLUE (Neutral)Fuse CarrierIEC Mains Connector6: Specifications 8000CD
