Specificmiows
VOLTAGE CONTROLLED OSCILLATOR
Frequency Range: 16Hz to 16KHz
Waveforms: Sawtooth, Square. Pulse. dynamic
pulse
Warm-up Drift: 1/30 Semitone from turn on
Tune Control Range: 2 1.5 semitones
Max. Vibrato Depth: 2 l octave
Max. Trill Depth: + 1.2 octaves
Max. ADSR Frequency Shilt: + 9 octaves
Pulse Width: 5% to 50%
Pulse Width Modulation: LFO. 1. 25%
ADSR. +45%
NOISE GENERATOR
Noise Spectrum Type: Pink. : 3d8 20Hz to
20KHz
VOLTAGE CONTROLLED FILTER
Frequency Range: 16 Hz to 16 KHZ
Maximum Usable Q: approx. 30
Resonance: 1/2 to self-oscillate
VC Response: approx. 1 v/oct.. same as VCO
Max. LFO Modulation: 1.5 octaves
Max. ADSR Sweep: 10 octaves
VOLTAGE CONTROLLED AMPLIFIER
Dynamic Range: 80d8
ADSR ENVELOPE GENERATOR
Attack Time: 5 ms to 5 seconds
Decay Time: 12 ms to 10 seconds
Sustain Level: 0 to 100% of peak
Release Time: 15 ms to 10 seconds
KEYBOARD
37 note standard AGO action
LFO
Wavelorms: sine, square
Frequency Range: 0.2Hz to 20Hz
Note: The LFO is clamped to the keyboard
trigger
SAMPLE AND HOLD
Sample Command Source: LFO square wave,
leading edge
Max. pitch deviation in VCO: 2.5 octaves
Max. frequency deviation in VCF: 2.5 octaves
