BXT210M Bass Monitor Cabinet 1: 1/4 Input/Output Jacks 2: Speakon ®Input/Output Jacks 3: High Frequency Horn Level Control The BXT210M Jackplate: 1 2 3 The Speakon ®and 1/4 jacks are wired in parallel, allowing easy daisy chaining from one speaker to another. Each of the jacks may be used as an input or a through connection. Speakon ®connectors are recognized as the standard for professional installations, assuring a secure, permanent connection that wont corrode, vibrate loose or be easily tampered with. The 1/4 jacks are convenient. However, the Speakon ®jacks are recommended when using power ampli- fiers over 150 watts, for permanent installations, or for the first speaker among a number of daisy chained speakers. Speakon to 1/4 W iring Diagram: 1+ 1- 1+ 1- ® Speakon ®is a registered trademark of Neutrik AG
