SAFETY INSTRUCTIONS
1. Read Instructions
All the safety and operation instructions should be read before using the product and retain them for future reference.
2. Water & Moisture
This product should not be used near water and will be protect from atmospheric agents in fixed or temporary installations.
3. Heat
This product should be situated away from heat sources such as radiators, or other devices which produce heat.
4. Liquid Entry
Care should be taken so that liquids are not spilled into the product and that objects do not fall on.
5. Service Assistance
This product should be serviced only by qualified service personnel when :
a.Liquids has spilled or objects have fallen into this product, or
b.This product has been exposed to rain, or
c.This product does not appear to operate normally or exhibits change in performance, or been dropped or itshas
cabinet / chassis damaged.
6. Package
The package of this product has been tested, inspect the package before open, if any damage is found, notify to
your dealer.
7. Hearing
This product produce high acoustic levels may cause permanent hearing loss, (SPL in for a defined period of time).
8. Installations
This product should be installed on the wall or in the floor with specific stands, according to the max weight.
"Electric discharge"
This symbol, alert you to the presence of uninsulated dangerous voltage inside the product which constitutes aenclosure,
risk of electric shock.
"Exclamatory point"
This symbol, alert the user to the presence of important operating and maintenance instructions the owner's manualin
included to the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Page 2
2
TABLE OF CONTENT
4. Technical Specifications ......................................................................................................................8
1. PAM5 Passive Live Monitor ...............................................................................................................3
1.1 Quick Start - Passive Speaker Cabinet
1.2 Input / Link Connections
2. PAM5A Active Live Monitor ...............................................................................................................5
2.1 Quick Start - Active Speaker Cabinet
2.2 Control Elements for PAM5A Rear Panel
3. PAM5T Installation Speaker Cabinet ................................................................. ........ ......................6
3.1 Quick Start Passive - Line 70.7/100V connection
3.2 Control Elements for PAM5T Rear Panel 1.3 Wire Connections
