ALTEC
8751A
Programmable Microaudio
14 Band Equalizer Module
KEY FEATURES
* Convenient Plug-in Module
* Wide Dynamic Range
* Unique Filter Arrangement
* Selectable Boost/Cut Steps
PRIMARY SPECIFICATIONS
Type:
Number of Bands:
Programmable Features:
Boost/Cut of each band:
Input circuitry,
Type:
Impedance:
Nominal Level:
Maximum Level:
Output circuitry:
Type:
Source Impedance:
Nominal Level:
Maximum Level:
Frequency Response:
Dynamic Range:
DESCRIPTION
The 8751A is a fourteen band programmable
MicroAudio equalizer module. The module plugs
directly into a main-frame l/O port of an Altec Lansing
1700C mixer/preamp; 1707C mixer/power amplifier
or 1715C mixer/power amplifier. Two male RCA
terminated leads extending from the rear connector
panel allow the equalizer to be connected in the
audio path between the pre-amp output and input of
the power amplifier being used. The equalizer
control is accessed only through a data port This
makes the equalizer tamper~proof. For more selectiv-
ity in equalization control, the 8751A utilizes a vari-
able, high Q filter circuit in each of the I4 bands.
Active analog filter set
14 bands located on ISO
center frequencies from 80
Hz to 6.3 kHz.
112 dB in 1 dB steps
:6 dB in '/2 dB steps
Unbalanced
15 kit
0 dBu (0.775 V rms)
+18 dBu
Unbalanced
100.
O dBu (0.775 V rms)
+18 dBm (+24 dBu into 2
k0 or greater load)
20 Hz - 20 kHz,
+0 dB,
> 105 dB (peak signal to
The internal microprocessor controls the amount
t 12 dB range. The equalizer module has a unique
SYSTEM REQUIREMENTS
AnyAltec [arising 1700C series mainframes will accommodate
available iron Altec Lansing. The model I700C Mixer/Pre-Amp
A-weighted background
noise)
of boost or cut for the 14 bands in 1 dB steps over a
filter band arrangement. One-third octave filters are
used for tuning of mid-band frequencies. The low
frequencies and high frequencies are adjusted using
one octave filters. The unique variable Q filter design
arrangement and tamper-proof control provide an
equalization function that enhances a I700 series
design vvithoul taking valuable rack space.
the 8751A. To program the 8751A one of the various Altec
Lansing programmers is needed. The programmers are the
Altec [arising 8055B Hand-Held Programmer, the 8061A PC
Controller Card, and the 8063A RS-232 Converter, each
does not have a power amp section. If the equalizer module
is used in this model, the equalizer will be used as an output
to drive another power amplifier unit only.
