Alpine TMX R705 Owners Manual

Page 1

1-EN Contents Operating Instructions WARNING WARNING .................................................. 2 CAUTION ................................................... 3 PRECAUTIONS ......................................... 3 Basic Operations Parts Names of the Overhead Monitor .............. 4 Opening the Monitor Display ............................ 5 Closing the Monitor Display .............................. 5 Adjusting the Monitor Viewing Angle ............... 6 Adjusting the Volume ........................................ 6 Audio Mute Function ......................................... 6 Switching the Source ......................................... 6 Switching Display Modes .................................. 7 Other Useful Features Adjusting Brightness of Picture ......................... 8 Adjusting Color Density of Picture ................... 8 Adjusting Tint of Picture .................................... 8 Setting the Brightness of the Backlight ............. 8 Adjusting the Lowest Level of the Backlight .... 9 Setting Automatic Closing of Monitor ............... 9 Dome Light Settings ........................................ 10 Battery Replacement ................................... 11 Replacing the Dome Light Bulb .................. 11 Information In Case of Difficulty ........................................ 12 Specifications ................................................... 12 Installation and Connections Warning ............................................................ 13 Caution ............................................................. 13 Precautions ....................................................... 14 Mounting Instruction ....................................... 15 Connections ..................................................... 16 LIMITED WARRANTY ENGLISH

Page 2

2-EN WARNING This symbol means important instructions. Failure to heed them can result in serious injury or death. DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE. Any function that requires your prolonged attention should only be performed after coming to a complete stop. Always stop the vehicle in a safe location before performing these functions. Failure to do so may result in an accident. KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE NOISE WHILE DRIVING. Failure to do so may result in an accident. MINIMIZE DISPLAY VIEWING WHILE DRIVING. Viewing the display may distract the driver from looking ahead of the vehicle and cause an accident. DO NOT DISASSEMBLE OR ALTER. Doing so may result in an accident, fire or electric shock. USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS. Use for other than its designed application may result in fire, electric shock or other injury. KEEP SMALL OBJECTS SUCH AS BATTERY OUT OF THE REACH OF CHILDREN. Swallowing them may result in serious injury. If swallowed, consult a physician immediately. DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION SLOTS OR GAPS. Doing so may result in personal injury or damage to the product. USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES. Failure to do so may result in fire or electric shock. WARNING DO NOT BLOCK VENTS OR RADIATOR PANELS. Doing so may cause heat to build up inside and may result in fire. DO NOT WATCH VIDEO WHILE DRIVING. Watching the video may distract the driver from looking ahead of the vehicle and cause an accident. INSTALL THE PRODUCT CORRECTLY SO THAT THE DRIVER CANNOT WATCH TV/VIDEO UNLESS THE VEHICLE IS STOPPED AND THE EMERGENCY BRAKE IS APPLIED. It is dangerous (and illegal in many states) for the driver to watch the TV/Video while driving the vehicle. The driver may be distracted from looking ahead and an accident could occur. If the product is not installed correctly, the driver will be able to watch the TV/Video while driving the vehicle and may be distracted from looking ahead causing an accident. The driver or other people could be severely injured.
