This is the 76 pages manual for Alpine DVA 7996 R Service Manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to email@example.com.
(Cautions for Safe Repair Work)
The following cautions will prevent accidents in the workplace and will ensure safe products.
.The symbols indicate caution is needed to prevent injuries and damage to property.
The symbols and their meanings follow.
serious injuw or death may result.
If you ignore this symbol and handle the product incorrectly or unsafely,
If you ignore this symbol and handle the product incorrectly or unsafely.
injury or only material damage may result.
.The following symbols indicate two levels of cautions
When you see this symbol. you have to be very careful,
When you see this symbol. you have to follow the instructions there.
Do not look squarely into the laser light
coming from the pickup.
You may loose you sight.
Always use a designated fuse.
Use of an incorrect fuse may result in a ﬁre.
Do not allow wiring to be caught in the
[f wiring is caught in the screw/chassis, it may cause
a short circuit, resulting in a ﬁre,
Use the designated battery.
Conﬁrm the correct polarity and seat of the battery.
An incorrect battery or an improperly connected or
seated battery may result in a ﬁre.
High Temperature Caution
Touching the heat sink may cause severe burns.
Designated Parts Caution
Look up the part list and ensure that only designated
parts are used to prevent problems or accidents.
Reverse Power Supply Connections or
Reverse power supply connections or misconnections
may cause ignition problems and smoke may result.
Ensure that the wiring is correct when rewiring to
prevent problems with ignition/breakdown.
Hot solder from solder splash may cause severe
Wear gloves to prevent electrical shocks or injury
from the end face of the metal.
For the FDA laser standard, the following CAUTION label is stuck on each product.
Please be careful for repair.
CAUTlON-Laser radiation when open, DO NOT STARE INTO BEAM
