Akai PDX 4440 Service Manual

This is the 12 pages manual for Akai PDX 4440 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 12
Akai PDX 4440 Service Manual

Extracted text from Akai PDX 4440 Service Manual (Ocr-read)


Page 1

Service Mama

COMPACT DISC COMPACT PLA YER

CONTENTS
Page
Specifications & Performance Specifications ............................................................................................ 1
Electrical Parts List ............... .. 2

Printed Circuit Boards ...........
Wiring Diagram ...................
Schematic Diagram ............
Voltage Chart ........................................................
IC Lead Identification & Internal Diagrams ...........
Block Diagram ....................................
Exploded Drawing Parts List ..............
Exploded Drawing ................................................................................................................................. 21

PD-X4440

PRODUCT SAFETY NOTICE

Many electrical and mechanical parts in this chassis have special safety characteristics.
These safety characteristics often pass unnoticed and the protection afforded by them cannot
necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
Replacement parts that have these special safety characteristics are identified in this manual
and its supplements; electrical components having such features are identified by $ in the
schematic diagram and the parts list.

Before replacing any of these components, read the parts list in this manual carefully.

The use of substitute replacement parts that do not have the same safety characteristics as
specified in the parts list may create shock, fire or other hazards.
