Akai DPS 24 Service Manual

This is the 29 pages manual for Akai DPS 24 Service Manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 29
left right
Akai DPS 24 Service Manual

Extracted text from Akai DPS 24 Service Manual (Ocr-read)


Page 2

* SAFETY INSTRUCTIONS

* INFORMATIONS

1. Parts identified by the A symbol are critical for safety.
Replace them only with the parts number specified.

2. In addition to safety, other parts and assemblies are
specified for conformance with such regulations as those
applying to spurious radiation.

These must also be replaced only with the specified

replacements.

Examples : Noise blocking capacitors, noise blocking filters,
etc.

3. Use specified internal wiring. Note especially :

1) Wires covered with PVC tubing
2) Double insulated wires
3) High voltage leads

4. Use specified insulating materials for hazardous live parts.

Note especially :

1) Insulation Tape

2) PVC tubing

3) Spacers (insulating barriers)

4) Insulation sheets for transistors

5) Plastic screws for fixing micro switches

5. When replacing AC primary side components (trans-
formers, power cords, noise blocking capacitors, etc.), wrap
the ends of the wires securely around the terminals before
soldering.

dab—I”

6. Make sure that wires do not contact heat producing parts
(heat sinks, oxide metal film resistors, fusible resistors,
etc.).

7. Check that replaced wires do not contact sharp edged or
pointed parts.

8. Also check areas surrounding repaired locations.

9. Make sure that foreign objects (screws, solder droplets,
etc.) do not remain inside the set.

SAFETY CHECK AFTER SERVICING

After servicing, make measurements of leakage-current or
resistance in order to determine that exposed parts are
acceptably insulated from the supply circuit. The leakage-
current measurement should be done between accessible
metal parts (such as chassis, ground terminal, microphone
jacks, signal input/output connectors, etc.) and the earth ground
through a resistor of 1500 ohms paralleled with a 0.15 pF
capacitor, under the unit's normal working conditions.

The leakage-current should be less than 0.5 mA rms AC. The
resistance measurement should be done between accessible
exposed metal parts and power cord plug prongs with the
power switch (If included) “ON”. The resistance should be
more than 2.2 M ohms.

SERVICE MANUAL

SYMBOLS FOR PRIMARY DESTINATION

Unit destinations are indicated with letters as shown below.

Symbols Principal Destinations
1 U.S.A
R England
Europe
Japan
Germany
Japan
Universal Area

MAKE YOUR CONTRIBUTION TO PROTECT THE
ENVIRONMENT

Used batteries with the ISO symbol for recycling as

well as small accumulators (rechargeable batteries), (D
mini-batteries (cells) and starter batteries should not @{9
be thrown into the garbage can.

Please leave them at an appropriate depot.

PRECAUTIONS FOR LITHIUM BATTERY
The lithium battery may explode when incorrectly replaced.
[OBSERVE THE FOLLOEING WHEN REPLACING]

- Replace with the same make and type or equivalent recom
mended by manufacturer.

0 Place battery in correct polarity.

0 Do not short the terminals.

0 Do not charge battery.

0 Do not dispose of battery in fire.
