Akai CS 30D 33D Service Manual

Extracted text from Akai CS 30D 33D Service Manual (Ocr-read)


Page 2

CASSETTE STEREO TAPE DECK

MODEL CS -33D

ALSO APPLICABLE '10 MODEL CS-30 CASSETTE
STEREO TAPE RECORDER & MODEL (IS-30D
CASSETTE STEREO TAPE DECK

SECTION 1
SECTION 2
SECTION 3
SECTION 4

SERVICE MANUAL ...................... 3
PARTS LIST ........................... 15
CONNECTION DIAGRAM .................. 32
SCHEMATIC DIAGRAM ................... 36

Page 9

V. HEAD ADJ USTM ENT

AZIMUTH
ALIGNMENT SCREW

Fig. 13

RECORDING/PLAYBACK HEAD AZIMUTH
ALIGNMENT ADJUSTMENT (See Fig. l2)

“Connect :1 High Sensitivity V.T.V.M, to the line
outputs.

I) Playback a 10 kHz pie-recorded tesl lapel

3D Turn Arimuth Alignment Screw to left and nght
and udjust lo ubtain maximum left/right channel
V.T.V,M. indication.

4| Always dcmagnetile heads following head adjust-
ments.
