Akai Innovators Catalog

Extracted text from Akai Innovators Catalog (Ocr-read)


Page 1

FULL LINE FOLDER

Page 2

STEREO TAPE RECORDER

The 1721 is priced for the budget-minded ...yet it-s
equipped with a 4-track stereo/monaural recording and
playback system, 2 Heads, Automatic Shut-Off. self-
lubricating 2-speed induction motor, Tape Selector
Switch, Pause Control and Public Address convertibility.
Available in a walnut finish (1721W) or leatherette finish
(1721L) cabinet.

SPECIFICATIONS
Tape Speed ................ 3% and 71/2 ips

Wow/Flutter ................ Less than 0.14% FIMS at 71/2 ips

Frequency Response ........ 30 to 18,000Hz at 71/2 ips

Distortion .................. Less than 2% (1000Hz "0" VU)

S/N Ratio ........ ....Better than 48dB

Reel Capacity .. ........... Up to 7- reel

Output Power .............. 10W total music power (SW/5W)
(SW/3W FIMS)

Speaker ................... 2 built-in-5-- x 7- speakers

Dimensions ................ 14.1'-(W) x 14.4"(H) x 9.3-(D)

Weight ..................... (1721W) 29 |bs.-(1721L)30.8 lbs.
