Akai AM M77 Owners Manual

This is the 22 pages manual for Akai AM M77 Owners Manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 22
left right
Akai AM M77 Owners Manual

Extracted text from Akai AM M77 Owners Manual (Ocr-read)

Page 1

,wt G ffifuWarning Miseengarde & Power requirements Power requirements for electrical equipment differ from area to area. Pleas ensure that your machine meets the power requirements in your area. If in doubt, consult a qualified electrician. 120V. 60Hz for USA and Canada 220V, 50Hz for Europe except UK 240V, 50Hz for UK and Australia ll0V /120V n20V lzrt0V, 50/60H2 switchable for orher countries. Voltage conversion Each machine is preset et the factory according to its desti- nation, but some machines can be set to 110V, 120V, 220V or 2ll{)V as required. lfyour machine's voltage can be converted: Before connecting the power cord, tum the VOLTAGE SELECTOR located on the rear panel with a screwdriver until the correct voltage is indicated. Models for USA, Europe, Canada and Australia are not equipp-ぎd with this facility. What you should know to protect yourself. Watch oul! You mlght got an oloctrlc shock. r Never touch the plug with wet hands. . Always pul out by the plug and never the cord. o Only let a qualified professional repair or reassemble the Akai Amplifier. An unauthorized person might touch the intemal parts and receive a serious electric shock. . Never allow a child to put anything, especially metal, into the Akai Amplifier. Lot's p.otoct th-ぎ Akai Amplltler too. . Use only a household AC power source. Never use a DC power source. . Ifwater is spilled on the Akai Amplifier disconnect and call your dealer. . Make sure that the Akai Amplifier is well ventilated and away from direct sunlight. Be careful not 1o block the side ventilator ofthe Akai Amplifier. o We recommend the use of the Akai Audio Rack. . To avoid damages to the internal circuits and the extemal surface, keep away from heat (stoves. etc.) . Avoid using spray type insecticide near the Akai Amplifier. It can damage the finish and might ignite suddenly. . To avoid damaging the finish, never use alcohol, paint thinner or other similar chemicals to clean the Akai Amplifier. . Place the Akai Amplifier on a flat and solid surface. . lf you don't plan to uso the Akai Amplilior tor a long porlod ot time, dis- connect tho poYver cord. The Akai Amplifier is not equipped with a power switch. To compleately tum off the Akai Amplifier, pull out the power cord. To enjoy the Akai Amplifier for a long time, please read this operator's manual thor- oughly. Puissance d'alimentation La puissance d'alimentation des appareils 6lectriques varie selon les pays. Veuillez vous assurer que votre appareil est conforme i la puissance d'alimentation de votre region. En cas de doute, mnsultez un 6lectricien qualifi6. 120V, 60Hz pour les Etats-Unis et le Canada 220V, 50Hz pour I'Europe saufle Royaume-Uni 2tl0V, 50Hz pour le Royaume-Uni et l'Australie ll0V /120V 1220V /240V, 50/50H2 commutable pour les autres pays. Conversion de la tension Chaque appareil est pr6r6gl6 en usine s-ぎlon sa destfuration, mais certains appareils peuvent 6tre 16916s sur I l0V, 120Y, 220Y ou 240V si n6cessaire. Si la tension de votre appareil peut 6tre chang6e: Avant de connect-ぎr le cordon secteur, toumez le selecteur de tension (VOLTAGE SELECTOR) situ6 sur le panneau arridre avec un toumevisjusqu'i ce que la tension correcte soit indiqu6e. Les moddles destin6s aux Etats-Unis, d I'Eu- rope, au Canada et e I'Australie ne sont pas 6quip6s de ce dispositif. Ce que vous devez savoir pour vous prot6ger Attentlon! Vous pourul-ぎz recevoir une d6charge 6lectrlqu-ぎ. . Ne touchez jamais la prise avec des mains humides. o D6branchez I'appareil en tenant la prise elle-m-ぎme et non pas le cordon. . Ne faites r6parer ou remonter I'amplificateur Akai que par un technicien de service. Une personne non qualifi6e pounait toucher des pieces intemes et recevoir une d6- charge 6lectrique dangereuse. o Nejamais laisser un enfant mettre quelque chose, en particulier en m6tal, dans I'amplificateur Akai. Prot6gez 6galem-ぎnt I'amplificat6ur Akai. . N'utilisez que des sources de courant secteur. N'utilisezjamais de sources d'ali- mentationCC. . Au cas oir de I'eau est renversee sur I'amplificateur Akai, d6connectez-le et prenez contact avec voue concessionnaire. o Assurez-vous que I'amplificateur Akai est bien a6r6 et hors d'atteinte des rayons di- rects du soleil. Faites attention de ne pas bloquer le c6te ventilateur de I'amplifica- teur Akai. o Nous recommandons I'utilisation du rack audio Akai. . Gardez I'appareil ir l'6cart de sources de chaleur (fours, etc.) pour 6viter d'endom- mager la surface ext6rieure ou lescircuits intemes. . Evitez d'utiliser des insecticides de type aerosol prds de I'amplificateur Akai. Ils pourraient endommager la finition et s'enllammer soudainement. . AIin d'6viter d'endommager la finition, n'utilisez jamais d'alcool, de diluants ou autres produits chimiques similaires pour nettoyer I'amplificateur Akai. o Placez I'amplificateur Akai sur une suface plane et solide. o El6connectez l-ぎ cordon socteur ai vous penaoz no pas utiliser I'amplifica- teur Akal p-ぎndant longtomps. L'amplificateur Akai n'est pas 6quip6 d'un commutateur d'alimentation. Pour mettre compldtement hors circuit I'amplificateur Akai, d6branchez le cordon secteur. Veuillez lire ce manuel dans son int6grite afin d'appr6cier I'amplificateur Akai pendant longtemps. The lightning flash with the arrowhead symbol superimposed across a graphical representation ofa person, within an equilateral triangle, is intended to alert the user to the presence ofuninsulated "dangerous voltage" within the product's enclosure; that may be ofsullicient magnitude to constitute a risk ofelectric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and mainte- nance (servicing) instructions in the literature accompanying the appliance. A /\ RISX OF ELECTRIC SHOCK OO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICIN.G TO QUALIFIED SERVICE PERSONNEL. -_, _-*J

Page 2

G W Precautions JL Elue(Neutral) (Neutral) FOR CUSTOMERS IN THE UK IMPORTANT FOR YOUR SAFETY The flex supplied with your machine will have either two wires or three as shown in the illustrations. THREE CORE FLEX WARNING THIS APPARATUS MUST BE EARTHED IMPORTANT creen/Yeilow The wires in this mains lead are coloured in accor- (Earth) dance with the following mde: Green-and-yellow: Earth Blue: Neutral Brown: Live As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked by the letter E or by the safety earth symbol * or coloured green or coloured green-and-yellow. The wire which is coloured blue must be connect- ed to the terminal which is marked with the letter N or coloured black. The wire which is coloured brown must be con- nected to the terminal which is marked with the letter L or coloured red. TWO CORE FLEX IMPORTANT The wires in this mains lead are coloured in accor- dance with the following code: Blue: Neutral Brown: Live As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.The wire which is coloured brown must be con- nected to the terminal which is marked with the letter L or coloured red. * Do not mnnect any wire to the larger pin marked E or * when wiring a plug. Ensure that all terminals are securely tightened and that no loose strands of wire exist. (Live) z*r Use No. l0 AWG (5.3 mm,) copper, No. 8 AWG (8.4mm,) aluminum. No. 17 AWG (1.0 mm2) copper-clad steel or bronze wire, or larger, as ground wlre. Secure antenna lead-in and ground wires to house with stand-off insulators soaced from 4 feet (1.22 m) to 6'feet (1.83 m)apart. Mount antenna discharge unit as close as possible to where lead-in enters house. I 2. 3. 5. 6 7 8 13. 14. 15. 16. 11. 18. 9. 10. ll. 12. SAFETY INSTRUCTIONS FOR CUSTOMERS IN THE U.S.A. FIGURE 1 EXAMPLE Otr ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODf,, INSTRUCTIONS MAST+ ANTENNA+LEAD IN WIRE b ITO RECEIVEF GROUNOWIRE a.b GFOUNDCLAMPS :: DRIVENS'INTOTHE- EARTH (2.44 METERS) Read Instructions-All the safety and operating instructions should be read before the equipment is operated. Retain Instructions-The safety and operating instructions should be retained for future reference. Heed Warnings-All warnings on the equipment and in the operating instrucions should be adhered to. Follow Instructions-All instructions for operating and use should be fol- lowed.Water and Moisture-The equipment should not be used near water-- for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc. Carts and Stands-The equipment should be used only with a cart or stand that is recommended by Akai. Wall or Ceiling Mounting-Akai does not recommend mounting the equipment on a wall or a ceiling. Ventilation-The equipment should b-ぎ situated so that its location or po- sition does not interfere with its proper ventilation. For example, the equipment should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openingsi or, placed in a built-in installation, such as a bookcase or cabinet that may impede the flow ofair through the ventilation openings. Heat-The equipment should be situated away from heat sources such as radiators, heat registers, stoves, or other equipment that produces heat.Power Sources-The equipment should be connected to a power supply only of the type described in the operating instructions or as marked on the equipment. Grounding or Polarization-Precautions should be taken so that the grounding or polarization means ofthe equipment is not defeated. Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the equipment. Cleaning-The equipment should be cleaned only as recommended by the manufacturer. Power lines-An outdoor antenna should be located away from power lines.Outdoor Antenna Grounding-Ifan outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electric Code, ANSI/ NFPA No. 70-1981, provides in- formation with respect to proper grounding of the mast and supporting structure, grounding ofthe lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements lor the grounding eleatrode. See Figure 1. Nonuse Periods-The power cord ofthe equipment should be unplugged from the outlet when left unused for a long period oftime. Object and Liquid Entry-Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings. Damage Requiring Service-The equipment should be serviced by quali- fied service personnel when: A. The power-supply cord or the plug has been damaged; or B. Objects have fallen, or liquid has been spilled into the equipment; or C. The equipment has been exposed to rain; or D. The equipment does not appear to operate normally or exhibits a marked change in performance; or E. The equipment has been dropped, or the enclosue damaged. Servicing-The user should not attempt to service the equipment beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel. l9
