— ENGLISH _

CAUTION
, nIsK 0F ELECTRIC SHOCK
Do NOT OPEN

”CAUTION:TO REDUCE THE RISK OF

ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL."

Explanation of Graphical Symbols:
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to alert
the user to the presence of uninsulated
“dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance

Owner’s record

For your convenience, record the model number and serial
number (you will find them on the rear of your unit) in the space
provided below. Please refer to them when you contact your
Aiwa dealer in case of difficulty.

Model No.
CX—ZL70
SX-WZL70
PX-E860

Serial No. (Lot No.)

PRECAUTIONS ,

Read the Operating Instructions carefully and completely before
operating the unit. Be sure to keep the Operating Instructions
for future reference. All warnings and cautions in the Operating
Instructions and on the unit should be strictly followed, as well
as the safety suggestions below.

Installation

1 Water and moisture— Do not use this unit near water, such
as near a bathtub, washbowl, swimming pool, or the like.

2 Heat — Do not use this unit near sources of heat, including
heating vents, stoves, or other appliances that generate heat.
It also should not be placed in temperatures less than 5°C
(41°F) or greater than 35°C (95°F).

3 Mounting surface — Place the unit on a flat, even surface.

2 ENGLISH

.fi:

4 Ventilation — The unit should be situated with adequate
space around it so that proper heat ventilation is assured.
Allow to cm (4 in.) clearance from the rear and the top of the
unit, and 5 cm (2 in.) from each side.

- Do not place the unit on a bed, rug, or similar surface that
may block the ventilation openings.

- Do not install the unit in a bookcase, cabinet, or airtight rack
where ventilation may be impeded.

5 Objects and liquid entry —— Take care that objects or liquid
do not get inside the unit through the ventilation openings.

6 Carts and stands — When placed or ‘
mounted on a stand or cart, the unit should "
be moved with care.

Quick stops, excessive force, and uneven
surfaces may cause the unit or cart to
overturn or fall.

7 Condensation — Moisture may form on the CD pickup lens
when:

— The unit is moved from a cold spot to a warm spot

- The heating system has just been turned on

- The unit is used in a very humid room

- The unit is cooled by an air conditioner

When this unit has condensation inside, it may not function
normally. Should this occur. leave the unit for a few hours,
then try to operate again.

8 Wall or ceiling mounting —The unit should not be mounted
on a wall or ceiling, unless specified in the Operating
Instructions.

Electric Bower

1 Power sources — Connect this unit only to power sources
specified in the Operating Instructions, and as marked on the
unit.

2 Polarization — As a safety feature, some units are equipped
with polarized AC power plugs which can only be inserted
one way into a power outlet. If it is difficult or impossible to
insert the AC power plug into an outlet, turn the plug over and
try again. It it is not still inserted easily into the outlet, please
call a qualified service technician to service or replace the
outlet. To avoid defeating the safety feature of the polarized
plug, do not force it into a power outlet.

3 AC power cord
- When disconnecting the AC power cord, pull it out by the

AC power plug. Do not pull the cord itself.

- Never handle the AC power plug with wet hands, as this
could result in fire or shock.

- Power cords should be firmly secured to avoid being severely
bent, pinched, or walked upon. Pay particular attention to
the cord from the unit to the power socket.

- Avoid overloading AC power plugs and extension cords
beyond their capacity. as this could result in fire or shook.

4 Extension cord —To help prevent electric shock, do not use
a polarized AC power plug with an extension cord, receptacle,
or other outlet unless the polarized plug can be completely
inserted to prevent exposure of the blades of the plug.

5 When not in use— Unplug the AC power cord from the power
outlet if the unit will not be used for several months or more.
When the cord is plugged in, a small amount of current
continues to flow to the unit, even when the power is turned
off.

Page 23

To change the time lag setting in Auto Vocal Fader or
Auto Multiplex function

The muted orijinal singer’s voice can be turned laster than the
normal level.

When Auto Vocal Fader or Auto Multiplex is selected, “A—VF” or
“A-MPX" is displayed for 3 seconds and disappears. Then hold
down KARAOKE until “FAST" is displayed.

To return to the initial setting, select SLOW.

When the power is turned off, SLOW is restored.

To change the audible channel in Multiplex function
Only the sound on the right channel can be heard from both
speakers.

When Multiplex is selected, “MPX-L" is displayed for 3 seconds
and disappears. Then the selected function name is displayed,
hold down KARAOKE until “MPX»R” is displayed.

To return to the initial setting, select MPX-L.

When the power is turned off, MPX—L is restored.

- The Karaoke functions may not operate correctly with the
following kinds of CDs or tapes.
-Those with monaural sound
~ Those recorded with strong echoes
- Those with the vocal part recorded on the right or left side of
the sound width
- While the Karaoke function is on, the sound is output as
monaural.
- When the function is changed, the Karaoke function is canceled.

co KARAOKE‘PROGRAM' t .

Before or during CD play, you can reserve up to 15 tracks to be
played alter the current track. Each reservation is cleared when
it finishes playing.

Use the remote control.
1 Press CD and load the discs.

2 Press PRGM me.
“CD KARAOKE” scrolls on the display.

3 Press DISC DIRECT PLAY, then one of the
numbered buttons 1-5 within 3 seconds to select
a disc.Then, press the numbered buttons 0-9 and
+10 to select a track.

Reserved Reserved track
disc number number

4 Repeat step 3 to reserve other tracks.

5 Press <> to start play.
After a track is played, it is cleared from the program.
Track number Currently

Currently. of the last playing track
playing disc reservation number flashes.

Disc number of the
last reservation

Number of remaining
reserved tracks

ENGLISH 23
