Aiwa AV D77 Owners Manual

Extracted text from Aiwa AV D77 Owners Manual (Ocr-read)


Page 1

1 ENGLISH ENGLISH Owner’s record For your convenience, record the model number and serial number (you will find them on the rear of your unit) in the space provided below. Please refer to them when you contact your Aiwa dealer in case of difficulty. Model No. Serial No. (Lot No.) AV-D77 PRECAUTIONS Read the Operating Instructions carefully and completely before operating the unit. Be sure to keep the Operating Instructions for future reference. All warnings and cautions in the Operating Instructions and on the unit should be strictly followed, as well as the safety suggestions below. Installation 1 Water and moisture — Do not use this unit near water, such as near a bathtub, washbowl, swimming pool, or the like. 2 Heat — Do not use this unit near heat sources, including heating vents, stoves, or other appliances that generate heat. It also should not be placed in temperatures less than 5°C (41°F) or higher than 35°C (95°F). 3 Mounting surface — Place the unit on a flat, even surface. 4 Ventilation — The unit should be situated with adequate space around it so that proper heat ventilation is assured. Allow 10 cm (4 in.) clearance from the rear and the top of the unit, and 5 cm (2 in.) from each side. - Do not place the unit on a bed, rug, or similar surface that may block the ventilation openings. - Do not install the unit in a bookcase, cabinet, or airtight rack where ventilation may be impeded. 5 Objects and liquid entry — Take care that objects or liquids do not get inside the unit through the ventilation openings. 6 Carts and stands — When placed or mounted on a stand or cart, the unit should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the unit or cart to overturn or fall. 7 Wall or ceiling mounting — The unit should not be mounted on a wall or ceiling, unless specified in the Operating Instructions. Electric P ower 1 Power sources — Connect this unit only to power sources specified in the Operating Instructions, and as marked on the unit. 2 Polarization — As a safety feature, some units are equipped with polarized AC power plugs which can only be inserted one way into a power outlet. If it is difficult or impossible to insert the AC power plug into an outlet, turn the plug over and try again. If it is not still inserted easily into the outlet, please call a qualified service technician to service or replace the outlet. To avoid defeating the safety feature of the polarized plug, do not force it into a power outlet. 3 AC power cord - When disconnecting the AC power cord, pull it out by the AC power plug. Do not pull the cord itself. - Never handle the AC power plug with wet hands, as this could result in fire or shock. - Power cords should be firmly secured to avoid being severely bent, pinched, or walked upon. Pay particular attention to the cord from the unit to the power socket. - Avoid overloading AC outlets and extension cords beyond their capacity, as this could result in fire or shock. 4 Extension cord — To help prevent electric shock, do not use a polarized AC power plug with an extension cord, receptacle, or other outlet unless the polarized plug can be completely inserted to prevent exposure of the blades of the plug. 5 When not in use — Unplug the AC power cord from the AC power outlet if the unit will not be used for several months or more. When the cord is plugged in, a small amount of current continues to flow to the unit, even when the power is turned off. WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. RISK OF ELECTRIC SHOCK DO NOT OPEN “CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.” Explanation of Graphical Symbols: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Page 2

n En ENGLISH 2 Remote control FM antenna AM antenna Operating Instructions, etc. Outdoor Antenna 1 Power lines — When connecting an outdoor antenna, make sure it is located away from power lines. 2 Outdoor antenna grounding — Be sure the antenna system is properly grounded to provide protection against unexpected voltage surges or static electricity build-up. Article 810 of the National Electrical Code, ANSI/NFPA70, provides information on proper grounding of the mast, supporting structure, and the lead-in wire to the antenna discharge unit, as well as the size of the grounding unit, connection to grounding terminals, and requirements for grounding terminals themselves. Maintenance Clean the unit only as recommended in the Operating Instructions. Dama ge Requiring Ser vice Have the unit serviced by a qualified service technician if: - The AC power cord or plug has been damaged - Foreign objects or liquid have gotten inside the unit - The unit has been exposed to rain or water - The unit does not seem to operate normally - The unit exhibits a marked change in performance - The unit has been dropped, or the cabinet has been damaged DO NO T A TTEMPT TO SER VICE THE UNIT YOURSELF . TABLE OF CONTENTS PRECAUTIONS ................................................................... 1 PREPARATIONS CONNECTIONS .................................................................. 3 BEFORE OPERATION ........................................................ 7 SOUND CUSTOM AUDIO ADJUSTMENT ....................................... 8 ELECTRONIC GRAPHIC EQUALIZER .............................. 9 DSP SURROUND .............................................................. 10 BASIC OPERATIONS SELECTION OF AUDIO/VIDEO SOURCE ....................... 11 RECORDING AN AUDIO SOURCE ................................. 12 RADIO RECEPTION MANUAL TUNING ............................................................. 13 PRESETTING STATIONS ................................................. 14 DOLBY SURROUND AND DTS SURROUND SELECTING DOLBY SURROUND ................................... 15 ADJUSTING DOLBY DIGITAL SURROUND SOUND ..... 18 SELECTING DTS SURROUND ........................................ 19 REMOTE CONTROL OPERATING TV, CABLE TV, VCR AND CD PLAYER ...... 20 TIMER SETTING THE CLOCK ...................................................... 21 SETTING THE SLEEP TIMER .......................................... 21 GENERAL SPECIFICATIONS ............................................................. 22 CARE AND MAINTENANCE ............................................ 23 TROUBLESHOOTING GUIDE .......................................... 23 PARTS INDEX ................................................................... 23 APPENDIX ID CODES FOR TV .......................................................... A-1 ID CODES FOR CABLE TV ............................................ A-3 ID CODES FOR VCR ...................................................... A-4 ID CODES FOR CD PLAYER ......................................... A-5 ID CODES FOR DSS SATELLITE .................................. A-6 Check your accessories ANTENNA LEAD IN WIRE ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250 PART H) NEC-NATIONAL ELECTRICAL CODE ELECTRIC SERVICE EQUIPMENT GROUND CLAMP Antenna Grounding According to the National Electrical Code
