r I II. I vuI-vuuiu rnI-vnu I run.) nnu our: I I Ina I nuv I IUIO
ARE REQUIREMENTS OF UL AND CSA SAFETY REGULATIONS
Warning: To reduce the risk ct lire or electric shocio'do not expose
this unit to rain or moisture.
RISK OF ELECTRIC SHOCK '
DO NOT OPEN .
AVIS: RISOUE DE CHOC ELECTRIQUE-NE PAS OUVRIR.
The graphic symbol of a lightning ﬂash with an arrow
point within a triangle signifies that there is dangerous
voltage within the unit and it poses a hazard to anyone
removing the coverto gain access to the interior oi the
unrt.0rtly qualified service personnel should make
any such attempt.
The graphic symbol oi an exclamation point within an
equilateral lrianola warns a user at the device that it is
necessary to reter to the instruction manual and its
warnings for proper operation at the unit.
Do not place this unit on an unstable cart. stand. tripod,
. bracket. or table. The unit may tall, musing serious
injury to a child or adult. and serious damage to the
unit. Use only with a can. stand. tripod. bracket, or table
recommended by the manutacturer. or sold with the
unit. Any mounting oi the device should iollow the man-
cessory recommended by the manutacturer.
Read all the saIely and operating instructions betore connecting or using
Retain this notice and the owners manual tor future reterence.
All wamirtgson the unit and inils operating instructions should be adhered to.
All operating and use instructions should he tollowed.
Do not use this unit near water; lot example. near a bathtub._washbowt.
kitchen sink. laundry tub. in a wet basement. or near a swrmrntng pool.
The unit should be installed so that itslocation or position does mt inlerterc
with its proper ventilation. For example. it should not be situated on I bed.
sota. rug. or smitar sunace that may I) the inﬂation minus. or
placed in a built-in installation. such as bookcase or cabinet. that may
impede the ﬂow of alr'through its ventilation openings.
The unit should be situated away irom heat sources such as radiators. heat
registers. slaves. or outer devices (including ampliﬁers) that produce heat.
The unit should be connected to a power-supply outlet only of the voltage
and frequency marked on its rear panel.
The power-supply cord should be routed so that it is not likely to be walked
on or pinched. especially nearthe plug. convenience receptacles. or where
the cord exits from the unit. '
Clean unit only as recommended in its inslmciion manual
The power-supply cord of the unit should be unplugged item the wall outlet
when it is to be unused tor a long period of time. >
Care should be taken so that objects do not tall. and liquids are not spilled,
into the enclosure through any openings.
This unit should be serviced by qualiﬁed service personnel when:
The power cord or the plug has been damaged: or
Objects have lotion. or liquid has been spilled. into the unit: or
The unit has been exposed to rain. or liquids ot any kind: or
The unit does not appear to operate normally. or exhibits a
marked diange in performance; or
The device has been dropped. or the enclOsure damaged.
DO NOT ATTEMPT SERVICING OF THIS UNI'II YOURSELF.
REFER SERVICING T0 QUALIFIED SERVICE PERSONNEL.
A1 I ENTIUN
POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS UTILISER
CEI'I'E FICHE POLARISEE AVEC UN PROLONGATEUR. UNE PRISE
m: murmur ou uNE AUTRE some DE COURANT. SAUF sr LES»: '
LAMES PEUVENT ETRE Insenées A FOND SANS EN musssa AU- 1; .
CUNE PARTIE A DECOUVERT.
TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG
WITH AN EXTENSION CORD. RECEPTACLE OR OTHER OUTLET UN«
lESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE
ulacturer's instructions. and should use a mounting ac-
Any outdoor antenna must be located away trorn all power lines.
OUTDOOR ANTENNA GROUNDING
It an outside antenna is connected to your tuner or tuner-preamplifier. be
sure the antenna symm is grounded so as to provide some protection
against voltage surges and built-up static charges. Section 810 or the
National Electrical Code. ANSI/NFPA No. 70-1984. provides information with
respect to proper grounding oi the mast and supporting structure. grounding
oi the load-In wire to an antenna discharge unit. size of grounding
conductors. location at antenna discharge unit. connection to grounding
electrodes. and requirements tor the grounding electrode.
8. Use No.10 AWG (5.3 mm) copper. No.8 AWG (8.4 mm) aluminum,
No.17 AWG (1.0 mm) copper-clad steel or bronze wire. or larger. as a
b. Secure antenna lead-in and ground wires to house with stand-oft
insulators spaced Iron 4.8 test (1 -1 as In) apart.
0. Mount antenna discharge unit as close as possible to where lead-tn
ewivalent. when a separate antenna-grunting electrode is used. See NEC
Section 810-21 0).
oar-rm NARNCLE cto mmnmrsrou soureusm
d. we jumper wire not smaller than No.6 AWG (13.3 mm) copper. or HIE)
BONDING JUMPER. d
. cerium. mm WONG
THE EARTH IF mo IV IOCAL
ooossssuecsecnouaruim f, }
NOTE TO CATV SYSTEM INSTALLER V
This reminder is provided to call the CATV system Installers attention to
Article 820-22 oi the National Electrical Code that provides guidelines for
proper grounding and. in particular. spedlles that the cable ground shall be .-
connected in the grounding systeri-Tot the Sirilding. as close to the point or
cable entry as practical.
