Adcom GTP 880 Owners Manual

This is the 52 pages manual for Adcom GTP 880 Owners Manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 52
left right
Adcom GTP 880 Owners Manual

Extracted text from Adcom GTP 880 Owners Manual (Ocr-read)


Page 1

| ADCOM GTP-880 Owner-s Manual 2 Dear fellow ADCOM product owner, Welcome to the ADCOM family! For more than twenty years, ADCOM products have delivered excellent performance and value for customers around the world. Our products are designed by our experienced and demanding engineering team, built to the highest standards in our factory, and sold and serviced through dealers, custom installers, and other retailers whose primary goal is your complete satisfaction. We know you are anxious to hear your new preamplifier in action, but please take a few minutes to read this owner-s manual before connecting the preamplifier to your system. It is particularly important that you connect your preamplifier to your amplifier while the amplifier and pream- plifier are unplugged and your other equipment is turned off. This will protect your equipment from potential short circuits that may occur during installion. In addition, it is important that you allow for adequate ventilation around your preamplifier and other equipment, since excessive heat buildup can shorten the life of any electronic product, including the preamplifier. Once you have correctly connected your new preamplifier to your other components, you should be able to enjoy many trouble-free years of performance. We conduct a thorough quality and performance test on each and every preamplifier we build in our factory prior to shipment. In the rare case of a defect that may occur after shipment, we stand behind our preamplifiers with a five-year parts and labor warranty. To register for this war- ranty, please complete and mail the enclosed warranty card back to ADCOM. Also, please keep a copy of your sales receipt with the owner-s manual so you may provide proof of eligibility for the warranty should the need arise. We know you will be very happy with the sound and performance of your new preamplifier. We hope you will also consider other ADCOM products, such as our line of multichannel amplifiers and DVD players. In addition, we design and manufacture complementary products such as surge sup- pressors and speaker selectors. Please visit our web site at www.adcom.com to learn more about our complete line of stereo, home theater, and distributed audio/video products. On behalf of all of us at ADCOM, I want to thank you for selecting our product for your home or business entertainment system. Sincerely, Douglas Klein President ADCOM A division of Klein Technology Group, LLC WELCOME

Page 2

3 Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Unpacking your GTP-880 . . . . . . . . . . . . . . . . . . . . . . 5 Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . 5 Description of Unit 1.1 Front Panel Illustration . . . . . . . . . . . . . . . . . . . . 6 1.2 Introduction to the GTP-880 . . . . . . . . . . . . . . . 6 1.3 Interface Overv iew . . . . . . . . . . . . . . . . . . . . . 6-9 1.4 Surround Formats . . . . . . . . . . . . . . . . . . . . . 9-10 1.5 Rear Panel Illustration . . . . . . . . . . . . . . . . . . . 12 1.6 Input & Output System Connections . . . . . 13-15 1.7 Connecting Components . . . . . . . . . . . . . . . 15-23 Remote Control 2.1 Remote Control Illustration . . . . . . . . . . . . . . . 24 2.2 Overv iew of the GRC-810 . . . . . . . . . . . . . . . . 25 2.3 Remote Features . . . . . . . . . . . . . . . . . . . . . 25-26 2.4 Remote Function Table . . . . . . . . . . . . . . . . 26-31 2.5 Programming the ADCOM GRC-810 . . . . . . . 32-33 2.6 Programming Macro Buttons . . . . . . . . . . . . . . 33 2.7 Function and Data List (Discrete) . . . . . . . 34-35 Setup 3.1 Setup Overv iew . . . . . . . . . . . . . . . . . . . . . . . . . 36 3.2 On Screen Display . . . . . . . . . . . . . . . . . . . . . . . 36 3.3 Input Configuration . . . . . . . . . . . . . . . . . . . 36-37 3.4 Speaker Configuration . . . . . . . . . . . . . . . . . 37-39 3.5 Channel Configuration . . . . . . . . . . . . . . . . . 39-41 Channel Calibration Channel Trim 3.6 Delay Configuration . . . . . . . . . . . . . . . . . . . 41-42 3.7 System Configurations . . . . . . . . . . . . . . . . . 42-43 3.8 Prologic II and Neo:6 Music Config . . . . . . 43-44 3.9 Room Two Configuration . . . . . . . . . . . . . . . 44-45 3.10 Additional Options . . . . . . . . . . . . . . . . . . . 45-46 Resolv ing Problems . . . . . . . . . . . . . . . . . . . . . . . . . 48 Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Caring for your GTP-880 . . . . . . . . . . . . . . . . . . . . . 50 Serv ice Information . . . . . . . . . . . . . . . . . . . . . . . . . 50 GTP-880 Specifications . . . . . . . . . . . . . . . . . . . . . . 51
