Congratulations!

Audio Dynamics Corporation (ADC) is proud to provide
the ultimate value in design and development of a 10
band graphic equalizer with a real time irequency spec-
trum analyzer, the Sound Shaper SS-315X for your super-
ior scund analysis. The Sound Shaper ss-atsx uses a
fluorescent indicator tube which has 100 separate seg-
ments plus 10 segments average response indicator for
display to analyze sound source frequencies and room
acoustics.

Audio fans and music enthusiasts like yourself look for-
ward to be able to enjoy the highest possible degress of
sound quality when listening to their favorite music.
Simply using high-cost. high-quality components, ho-
wever. does not in itsell guarantee that the listener will be
able to obtain this sound quality.

A wide variety of factors. including the nature of the lis-
tening environment as well as the placement of
speakers, play a major role in the accoustic quality of any
music system. To further enhance the effectiveness of

WARNING:
To prevent fire or shock hazard, do not ex-
pose this appliance to rain or moisture.

In the space provided below. record the serial number
of your unit. located on tm back at the cabinet.

Unit description
STEREO FREQUENCY EOIIALIZER
Sound Shaper 88-315)!

Serial No

Retain this number for future reterence

the audio equalizer, ADC has developed the ultimate
component in audio measuring equipment: the new
SS-315X. the graphic equalizer with a real time frequency
spectrum analyzer.

The SS-315X offers the listener positive visual confirma-
tion of all sound compensation made. having combined
a graphic equalizer and spectrum analyzer both into one
unit.

The fluorescent indicator tube's display. which allows vi-
sual monitoring of all frequencies. plus average re-
sponse, adds a further dimension of pleasure to the use
of this superior component.

A high quality electret condenser microphone has been
developed exclusively for pink noise measurement and
is included with your SS-315X. in addition to the excel-
lent styling, your SS-315X has been carefully engineered
to give you trouble-free perlormance and many years ol
listening enjoyment.

RISK or ELECTRIC SHOCK '
00 NOT OPEN 0

/\

CAUTION: TO REDUCE THE RISK OF ELECv
TRIC SHOCK. DO NOT REMOVE
COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SER-

VICE PERSONNEL.
