About Variable-Level Audio Outputs:
A variable-level output, such as a headphone jack or certain RCA-type outputs, provides an
audio signal that changes with the volume level set on the audio source. As the volume of the
audio source is adjusted up and down, so is the audio signal strength sent to the transmitter.
This can affect the quality of sound generated by the speaker, and may require an adjustment
of the volume level of the audio source to produce a signal strong enough for the transmitter.
Hint: On most bookshelf-type or compact stereo systems, inserting a headphone plug into
the headphone jack results in automatic cutoff of the regular, or hard-wired speakers.
Hint: Most TVs, regardless of age or price, have variable outputs. If you are unsure which
of your TV audio outputs is fixed, refer to the TV instruction manual. Some TVs have
outputs that can switch between variable and fixed. When given a choice, fixed is always
recommended.
Troubleshooting
The following troubleshooting guide takes you through some of the more common problems
associated with the installation and/or operation of a wireless system. If the problem persists,
please call toll-free at 1-800-732-6866 or visit www.araccessories.com.
Issue: Cause and solution:
No sound - Check that the transmitter AC power adapter is fully inserted into the wall outlet and
the power cord from the AC adapter is firmly connected to the transmitter power
input jack.
- Confirm that the speaker is turned on and tuned to the transmitter
the indicator light on the front of the speaker should be green.
- Make sure the speakers batteries are fresh and inserted with correct polarity (+, ). Replace if necessary.
- Check that the audio source component (stereo, MP3 player, etc.) is turned on and transmitting sound as it normally should.
- Make sure the volume on your audio source is turned up.
- Check that the speaker volume is turned up.
- If you are using a Tape 2 Monitor output from your receiver/amp as the audio output, check that you have pressed the Tape Monitor/Tape 2 button on the front of
the receiver. This will turn on the Tape 2 outputs, which may not have been active.
More Helpful Information
About Fixed-Level Audio Outputs
A fixed-level, or line-level, audio output is considered ideal since it provides an audio signal
unchanged by adjustments to the audio source volume control.
Hint: Fixed-level audio outputs from stereo receivers/amps will typically be designated as
Tape (or Record) outputs or DVR/DVD-R audio output connections.
Fixed-level outputs from TVs are usually marked as Constant, Fixed, or Select. If they are not
marked as such, they are probably variable outputs (see About Variable-Level Audio Outputs on
the next page). Outputs from DVD players are almost always fixed.
Hint: When connecting to the audio outputs of a DVD player, remember that the DVD player
must be showing a TV channel for sound to be produced.
