K A-7 6 KENWOOD
INSTRUCTION MANUAL FILE

LCPRiNTED IN JAPAN ESQ-662300. P. U UEKT}
85/55432187112111098765432

Rear panel safety precautions

CAUTION CAUTION, TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
msmrstgcmcsuocx IOR BACK) NO USERVSERVICEABLE PARTS INSIDE. REFER SERVICING TO
00 mm 0pm QUALIFIED SERVICE PERSONNEL.

The lightning flash WIth arrowhead symbol, within an equilateral triangle, is Intended to
alert the user to the presence of umnsulated "dangerous voltage" withIn the products
enclosure; that may be Of sufficient magnitude to constitute a risk of electric shock to
persons,

The exclamatlon pOInt WIthIn an equilateral triangle Is Intended to alert the user to the
presence of Important Operatlng and maintenance (serVICIngl instructions In the
Immune accomoanvina the aoollance

Page 2

For your records

Record the serial number, found on the back of the
unit, in the spaces de8ignated on the warranty card,
and in the space provided below Refer to the model
and serial numbers whenever you call upon your dealer
for information or service on this product

Model Serial Number

Unpacking

Unpack the unit carefully and make sure that all ac»
cessories are put aSide so they Will not be lost.
Examine the unit for any pOSSIbility of shipping
damage it your unit lS damaged or fails to operate,
notify your dealer immediately. If your unit was shipped
to you directly, notify the shipping company Without
delay Only the consignee (the person or company
recewing the unitl can file a claim against the carrier for
shipping damage

We recommend that you retain the original carton and
packing materials for use should you transport or ship
the unit in the future

Before applying power

Important!

l i
I U.S.A. and Canada '
i Units shipped to the U.S A. and Canada are I
de3igned for operation on 120 volts AC only i
These units are not eowpped With an AC voltage
selector sWitch and the discuSSion of such a
swnch that follows should be disregarded
l

All other countries i

Units shipped to countries other than the U.S.A. i

and Canada are equipped With an AC voltage

selector swrtch on the rear panel Refer to the

tollowmg paragraph for the proper setting of this
, SWitch.

AC voltage selection

This unit operates on 110120 or 2207240 volts AC
The AC voltage selector swnch on the rear panel is set to
the voltage that prevails in the area to which the unit is
shipped. Before connecting the power cord to your AC
outlet, make sure that the setting posmon oi this sWitch
matches your line voltage. If not, it must be set to your
voltage in accordance With the tollowmg direction.

Note:
Our warranty does not cover damage caused by excessive line
voltage due to improper setting of the AC voltage selector swuch

l AC110-120VN4 > AC220»24OV~ AC110-120VN4 > AC2207240V/x.
l

This shows swrtch

\

G

This shows switch
lever locked in the lever locked In the

110120 V\. posi- 2207240 Vv posi
tion. tion.

Move swltch lever to match your line
Voltage with a small screwdriver or other
pointed tool.

AC voltage selector switch

Safety precaution for AC plug (for U.S.A and
Canada)

CAUTION:

TO PREVENT ELECTRIC SHOCK DO NOT USE
THIS (POLARIZED) PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY INSERTED
TO PREVENT BLADE EXPOSURE.

WARNING:
TO PREVENT FIRE OR ELECTRIC
SHOCK. DO NOT EXPOSE THIS AP-
