Important!
U.S.A.. Canada
Units shipped to the U.S.A. and Canada are designed
for operation on 120 volts AC only. These units are not
equipped with an AC voltage selector switch and the
discussion of such a switch that follows should be
disregarded.
Allother countries
Units shipped to countries other than the U.S.A.,
Canada are equipped with an AC voltage selector
switch on the rear panel. Refer to the following
paragraph for the pr0per setting of this switch.
AC voltage selection
This unit operates on 120 volts, 220 volts or 240 volts AC.
The AC voltage selector switch on the rear panel is set to the
voltage that prevails in the area to which the unit is shipped.
Before connecting the power cord to your AC outlet, make
sure that the setting position of this switch matches your line
voltage. If not, it must be set to your voltage in aCCOrdance
with the following direction.
Note:
Our warranty does not cover damage caused by excessive line
voltage due to improper setting of the AC voltage selector switch.
WARNING:
TO PREVENT FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
Rear panel safety precautions
AC 120 V~4AC 220 be AC 240 V\.
This shows switch
lever locked in the
AC 120 V»
II position.
I. This shows swutch
AC 120 V~
II position.
I. This shows Switch
lever locked in the
AC 240 V»
I. DOSition.
Move switch lever to match your line voltage.
AC 120 onAC 220 V~>AC 240 Va.
AC voltage selector switch
For United Kingdom
The mains plug must be removed from the wall socket
prior to any internal examination.
Important
The wires in this mains lead are coloured in accordance
with the following code:
Blue ...................................... Neutral
Brown ................................... Live
The wires in this mains lead must be connected to the
terminals in the plug as follows:
Wire Colour Plug Terminal Marking
Blue ...................................... N or Black
Brown ................................... L or Red
F ()5
Brown to _
Live 4
Blue to __, '-
Neutral f
Notes:
1) If a 13-amp plug is used, this must be fitted with a 5-amp
fuse.
2) If a 3-pln plug with earthing contact is used, no wire
must be connected to the E terminal.
CAUTION
RISK OF LLI (,ITRIC SHOCK
[)0 NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
persons.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated dangerous voltage" within the product's
enclosure; that may be of sufficient magnitude to constitute a risk of electric shock to
The exclamation point within an eQUilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
2 KA-I iOOSD (KI
