Cec Concord BA 300 Owners Manual

Page 2

WARNING: TO PREVENT FIRE OR SHOCK HAZARD. DO NOT
EXPOSE THIS APPLIANCE T IN OR MOISTURE.

DUST COVER

FRICTION HINGE

ADAPTOR FOR 45 RPM.

CENTER LATERAL WEIGHT

SPINDLE I

CALIBRATION RING

COUNTER WEIGHT

\ _ .
I \VL CUEING DEVICE

TURNTABLE MAT-

SPEED

CHANGEOVER
LEVER

II; . -_ ANTI-SKATING

TURNTABLE _ L-
PLATTER _ - CUEING LEVER
BASE TONE ARM SUPPORT
TONE ARM
CHASSIS REJECT LEVER

HEADSHELL

Page 4

B. Assembly and Adjustment of the
Turntable Assembly

1.

2.

Remove the two screws which
clamp the motor. (See Figure 2)
Loosen the two screws which clamp
the chassis to the base. When sufficiently
loosened, the screws will snap up to
their maximum position and the
chassis will ride freely on its springs.
NOTE: If the turntable is to be
shipped or transported, the motor
clamping screws must be replaced
and tightened as well as the chassis
clamping screws.

Untie the ribbon which restrains the
tone arm. Remove the Styrofoam
block from under the rear of the

Screws for clamping
motor (remove)

Screws for clamping
chassis (loosen)

HGURE2

Rubber belt

tone arm. Carefully remove the
strip of tape from the plastic gear.
Carefully remove the rubber band
from the antiskating device.

. Carefully lower the turntable platter

onto the center spindle. Slowly turn
the platter in a clockwise direction
until the motor shaft is centered in
one of the two large openings in the
platter. (See Figure 3) Set the speed
changeover lever to.33 1/3. Clean
your hands of all oil and grease to
avoid contamination of the belt.
Grasp the belt (See Figure 4) and
slip it over the motor shaft as in
Figure

HGURE3
