Casio ctk 330 service manual
This is the 16 pages manual for casio ctk 330 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from casio ctk 330 service manual (Ocr-read)
Page 1
Ñ 2 Ñ CONTENTS Specifications .......................................................................................................................... 2 Block Diagram ......................................................................................................................... 3 Circuit Description ................................................................................................................... 4 Major Waveforms .................................................................................................................... 7 Schematic Diagrams ............................................................................................................... 8 Printed Circuit Board ............................................................................................................. 10 Exploded View ...................................................................................................................... 11 Parts List ............................................................................................................................... 13 SPECIFICATIONS GENERAL Number of keys: 49 Polyphonic: 12-note Preset tones: 100 Auto-rhythms: 50, Tempo control: 40 to 255 Accompaniment: Casio Chord, Fingered Song bank: 20-tune Tuning control: 440 Hz ± 50 cents Built-in speakers: 4 inch dia. 2 W input rating: 2 pcs Terminals: Stereo standard Jack (Output impedance: 100 ohm, Output voltage: 3 V (rms) MAX Power source: 2-way AC or DC source AC: AC adapter DC: 6 AA size dry batteries Power consumption: 7.2 W Dimensions(HWD): 988 ´ 311 ´ 125 mm (38-15/16 ´ 12-1/4 ´ 4-15/16 inches) Weight: 3.5 kg (7.7 lbs) excluding batteries ELECTRICAL Current drain with 9 V DC: No sound output 120 mA ± 30% Maximum volume 650 mA ± 30% with white keys C1 to G2 pressed in Synth-Lead 1 Volume: 9 Phone output Level (Vrms with 8 ohm load each channel): with key E3 pressed in Synth-Lead 1 80 mV ± 30% Sound Pressure (at 10 cm away from speaker): with key E3 pressed in Synth-Lead 1 100 dB ± 10 dB Minimum operating voltage: 6.0 V
Page 2
Ñ 3 Ñ CPU MSM 6755B-08 LSI101Keyboard Buttons LED Reset IC IC102Oscillator X101, Q107 Q111 Power Supply Circuit Q101 ~ Q104, D106 Power Amp. LA4598 IC101Filter (L) Q105 Filter (R) Q106 Output DC+9V IN VC AVDD DVDD LVDD APOCC1 ~ CC3La ~ Lg, Lp KO8 ~ KO11KI0 ~ KI7 KO0 ~ KO7 BLOCK DIAGRAM
