ME-5

June, 1988

EXPLODED/fiflB-l

b-W-fi

O 0 E
2J0 o-@

000 000 Op 000 000 O 0 1-4

o 0°11;
l

Bottom Cover Removal Screws.

®x6

fifilfiBfl-E

SCREWS

3 x 8 mm Binding Tap-tight (self-Tapping) 8 Type FeBc x 2

2 3 x 4 mm Binding Machine FeBc x 2
3 3 x 8 mm Binding Tap-tight lself-Tapping) P Type FeBc x 2
4 3 x 8 mm Binding Tap-tight (self-Tapping) S Type FeBc w/Tooth Washer x 5
5 3 x 8 mm Binding Tap~tight (self-Tapping) S Type FeCm w/Tooth Washer x 5
0 3 x16 mm Binding Tapping B1 FeCm x 2
7 3 x 8 mm Binding Tap-tight (self-Tapping) S Type FeBc x 4
8 3 x 6 mm Binding Machine FeCm x 2
10 External Tooth Washer
11 8 mm Binding Tap-tight (self»Tapping) 8 Type FeBc w/Tooth Washer x 6
12 8 mm Binding Tap-tight (self-Tapping) S Type FeBc x 10
PARTS
13 ME-5 LED Mask B 2226038900
14 ME-S LED Mask A 2226039000
15 Button #247-606 2247060600
16 Cord Bushind BU-2 12369510
17 Cord Holder #219-784 2219078400
18 ME-S Jack Holder #143 2220014300
19 Bottom Base #312 2235031200
20 ME-5 Bottom Cover 2202038300
21 Pedal Escutcheon 11222-321 2222032100
22 Switch Pedal it 11218-605 2218060500
23 Support Spring 2217010300
24 Rubber Foot #35
25 ME-5 Panel 2221081600
26 ME-5 Button 13288 2249020800
27 ME-5 Top Cover 2202038200
